CF app route unmap

CF app route unmap temporarily unmaps a Cloud Foundry app route and later maps it back to the app.

CF App Route Unmap

Use cases

CF app route unmap:

Checks resilience against abrupt un-mapping of an app route.
Validates the effectiveness of disaster recovery and high availability of the app.

Mandatory tunables

Tunable	Description	Notes
organization	Organization where the target app resides.	For example, `dev-org`.
space	Space where the target app resides.	The space must reside within the given organization. For example, `dev-space`.
app	The app to be stopped	The app must reside within the given organization and space. For example, `cf-app`.
host	Host name of the route to be unmapped.	For example, `v1`. For more information, go to host.

Optional tunables

Tunable	Description	Notes
faultInjectorLocation	Fault injector placement with respect to where the LCI is hosted.	Default: `local`. Supports `local` and `vSphere`. For more information, go to Fault Injector location.
path	Path of the route to be un-mapped.	For example, `/cart`. For more information, go to path.
port	Port of the route to be un-mapped.	For example, `8080`.
faultInjectorPort	Local server port used by the fault-injector utility.	Default: `50320`. If the default port is unavailable, a random port in the range of `50320-51320` is selected. For more information, go to fault injector port.
duration	Duration through which chaos is injected into the target resource (in seconds).	Default: 30s. For more information, go to chaos duration.
skipSSLValidation	Skip SSL validation while invoking CF APIs.	Supports `true` and `false`. Default: `false`. For more information, go to skip SSL validation.
rampTime	Period to wait before and after injecting chaos (in seconds).	Default: 0s. For more information, go to ramp time.

CF secrets

The following Cloud Foundry secrets reside on the same machine where the chaos infrastructure is executed. These secrets are provided in the /etc/linux-chaos-infrastructure/cf.env file in the following format:

CF_API_ENDPOINT=XXXXXXXXXXXXXXXXXXX
CF_USERNAME=XXXXXXXXXXXXXXXXXXXXXXX
CF_PASSWORD=XXXXXXXXXXXXXXXXXXXXXXX
UAA_SERVER_ENDPOINT=XXXXXXXXXXXXXXX

info

If the secrets file is not provided, the secrets are attempted to be derived from environment variables and the config file by the fault-injector.

ENV name	Description	Example
CF_API_ENDPOINT	API endpoint for the CF setup	`https://api.system.cf-setup.com`
CF_USERNAME	Username for the CF user	`username`
CF_PASSWORD	Password for the CF user	`password`
UAA_SERVER_ENDPOINT	API endpoint for the UAA server for the CF setup	`https://uaa.system.cf-setup.com`

Fault injector ENVs and config file

If /etc/linux-chaos-infrastructure/cf.env file is not provided, fault-injector attempts to derive the secrets from environment variables or a configuration file. Any secret that is re-declared will be overridden in the following order of decreasing precedence:

/etc/linux-chaos-infrastructure/cf.env file
Environment variables
Configuration file

The configuration file should be provided at /etc/linux-chaos-infrastructure/cf-fault-injector.yaml:

cf-api-endpoint: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
username: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
password: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
uaa-server-endpoint: XXXXXXXXXXXXXXXXXXXXXXXXXX

A mapping between all the three formats for providing the secrets is as follows:

cf.env	ENV	cf-fault-injector.yaml
CF_API_ENDPOINT	CF_API_ENDPOINT	cf-api-endpoint
CF_USERNAME	USERNAME	username
CF_PASSWORD	PASSWORD	password
UAA_SERVER_ENDPOINT	UAA_SERVER_ENDPOINT	uaa-server-endpoint

vSphere secrets

These secrets are provided only if vSphere is used as the deployment platform for CF.

The following vSphere secrets reside on the same machine where the chaos infrastructure is executed. These secrets are provided in the /etc/linux-chaos-infrastructure/vsphere.env file in the following format:

GOVC_URL=XXXXXXXXXXXXXXXXXXXXXX
GOVC_USERNAME=XXXXXXXXXXXXXXXXX
GOVC_PASSWORD=XXXXXXXXXXXXXXXXX
GOVC_INSECURE=XXXXXXXXXXXXXXXXX
VM_NAME=XXXXXXXXXXXXXXXXXXXXXXX
VM_USERNAME=XXXXXXXXXXXXXXXXXXX
VM_PASSWORD=XXXXXXXXXXXXXXXXXXX

ENV Name	Description	Notes
GOVC_URL	Endpoint for vSphere	For example, `192.168.214.244`
GOVC_USERNAME	Username for the vSphere user	For example, `username`
GOVC_PASSWORD	Password for the vSphere user	For example, `password`
GOVC_INSECURE	Skip SSL validation for govc commands	For example, `true`
VM_NAME	Name of the vSphere VM where the fault-injector utility is installed	For example, `cf-vm`
VM_USERNAME	Username for the VM guest user	For example, `root`
VM_PASSWORD	Password for the VM guest user	For example, `password`

Fault Permissions

Lists all apps that the user or system has visibility into

Required Roles (any one):

SpaceDeveloper
SpaceAuditor
OrgManager
OrgAuditor

Required OAuth Scopes (any one):

cloud_controller.read
cloud_controller.admin
cloud_controller.global_auditor

Fetch routes associated with a specific app

Required Roles (any one):

SpaceDeveloper
SpaceAuditor

Required OAuth Scopes (any one):

cloud_controller.read
cloud_controller.admin
cloud_controller.global_auditor

Remove (unmap) a specific route from the given app

Required Role:

SpaceDeveloper (in the space where the app exists)

Required OAuth Scopes (any one):

cloud_controller.write
cloud_controller.admin

Associate (map) a specific route with an app

Required Role:

SpaceDeveloper

Required OAuth Scopes (any one):

cloud_controller.write
cloud_controller.admin

Host

The host input variable determines the host of the route which is un-mapped. For example, for a route http://example-app.shared-domain.example.com, the host is example-app.

The following YAML snippet illustrates the use of this input variable:

# host for the route
apiVersion: litmuchaos.io/v1alpha1
kind: LinuxFault
metadata:
  name: cf-app-route-unmap
  labels:
    name: app-route-unmap
spec:
  cfAppRouteUnmap/inputs:
    duration: 30
    faultInjectorLocation: vSphere
    app: cf-app
    organization: dev-org
    space: dev-space
    host: example-app

Path

The path input variable determines the path of the route which is un-mapped. For example, for a route http://example-app.shared-domain.example.com/abc, the path is /abc.

The following YAML snippet illustrates the use of this input variable:

# host and path for the route
apiVersion: litmuchaos.io/v1alpha1
kind: LinuxFault
metadata:
  name: cf-app-route-unmap
  labels:
    name: app-route-unmap
spec:
  cfAppRouteUnmap/inputs:
    duration: 30
    faultInjectorLocation: vSphere
    app: cf-app
    organization: dev-org
    space: dev-space
    host: example-app
    path: /abc

Fault Injector location

The faultInjectorLocation input determines the fault injector placement with respect to where the LCI is hosted.

It supports one of:
- local: LCI and fault injector are placed in the same machine.
- vSphere: Fault injector is placed in a remote vSphere managed VM.

The following YAML snippet illustrates the use of this environment variable:

# Fault Injector location
apiVersion: litmuchaos.io/v1alpha1
kind: LinuxFault
metadata:
  name: cf-app-container-kill
  labels:
    name: app-container-kill
spec:
  cfAppContainerKill/inputs:
    duration: 30s
    faultInjectorLocation: vSphere
    app: cf-app
    organization: dev-org
    space: dev-space

Skip SSL validation

The skipSSLValidation input variable determines whether to skip SSL validation for calling the CF APIs.

The following YAML snippet illustrates the use of this input variable:

# skip ssl validation for cf
apiVersion: litmuchaos.io/v1alpha1
kind: LinuxFault
metadata:
  name: cf-app-route-unmap
  labels:
    name: app-route-unmap
spec:
  cfAppRouteUnmap/inputs:
    duration: 30
    faultInjectorLocation: vSphere
    app: cf-app
    organization: dev-org
    space: dev-space
    skipSSLValidation: true

Fault injector port

The faultInjectorPort input variable determines the port used for the fault-injector local server.

The following YAML snippet illustrates the use of this input variable:

# fault injector port
apiVersion: litmuchaos.io/v1alpha1
kind: LinuxFault
metadata:
  name: cf-app-route-unmap
  labels:
    name: app-route-unmap
spec:
  cfAppRouteUnmap/inputs:
    duration: 30
    faultInjectorLocation: local
    app: cf-app
    organization: dev-org
    space: dev-space
    faultInjectorPort: 50331
